Retrofit a classic parallel port via PCIe
Continue using legacy peripherals:IEEE 1284-compatible parallel port connects existing parallel devices to current computers.
Suitable transfer mode for each application:Supports SPP, PS2, EPP and ECP.
Easy integration into PCIe systems:Single-lane x1 per Revision 1.1 with up to 2.5 Gb/s bus throughput.
Tidy in-chassis retrofit:Installed directly in the PCIe slot, without external adapters.
This PCIe interface card adds a parallel 25-pin interface to desktop or workstation systems. The port is IEEE 1284-compatible and supports SPP, PS2, EPP and ECP, so existing parallel devices remain connected. With its single-lane (x1) architecture per Revision 1.1 and up to 2.5 Gb/s, the card integrates into modern systems.
In professional IT environments, for on-site installations and in service deployments, the card facilitates continued operation of existing infrastructures on current computers without a native parallel port. Support for common operating systems from Windows 2000 to Windows 10 as well as Linux, Mac OS X 10.5 and DOS 6.22 simplifies integration in companies and public institutions.
Port:1x 25-pin Sub-D socket (parallel)
Host interface:PCI Express x1, Revision 1.1
Throughput:up to 2.5 Gb/s
Standard:IEEE 1284
Modes:SPP, PS2, EPP, ECP
Controller:MCS9900CV-AA
